Vibratory Weigh Filler Granule Packing Machine | 2DC-2K
Semi-Automatic Vibratory Weigh Filler Machine
Semi-automatic vibratory weigh filler machine mainly applies to granule, granule-powder mixture, strips, blocks, and other materials’ quantitative filling and packaging. Such as: pesticides, fertilizers, feed, Chinese Herbal Medicines, Chinese medicine granules, premix, detergent powder, casual snacks, candies, melon seeds, peanuts, salt, monosodium glutamate, chicken powder, beans, grains, seeds, hardware and other granular materials’ weighing and quantitative filling.
Page Contains:
1. Features:
- 1. Firstly, the HMI of vibratory weigh filler are LCD touch screen with double languages of Chinese and English.
- 2. Easy to operation.
- 3. High precision linear weigher scales feeding materials.
- 4. Filling weighing accuracy is greater than 99.7%.
- 5. Optional from photoelectric sensors and footpad switch (The default is photoelectric sensors).
- 6. Machine starting up electronic scale automatic set zero, packing weight exceed accuracy limit alarm.
- 7. In addition, weighing error can be automatically corrected, vibrators amplitude voltage is adjustable.
2. Technical Parameters:
- Model
- Brand
- Metering Range
- Filled Error
- Weighing Hoppers
- Weighing Speed
- Feeding Method
- Hopper Volume
- Silo Volume
- Ground Clearance
- Voltage
- Power
- Dimensions
-
2DC-2K Vtops
- VTOPS-2DC-2K
- VTOPS
- 30-2000 g
- ≤ ±0.3%
- 2
- 0-30 fills/min
- Vibrator Fillers
- 4.5 Liters
- 100 Liters
- 650 mm
- AC Single-phase 220V
- 0.5 Kw
- 108×95×192 cm
-
4DC-2K Vtops
- VTOPS-4DC-2K
- VTOPS
- 30-2000 g
- ≤ ±0.3%
- 4
- 0-50 fills/min
- Vibrator Fillers
- 3 Liters
- 120 Liters
- 780 mm
- AC Single-phase 220V
- 0.5Kw
- 131×107×242 cm
-
2DC-6K Vtops
- VTOPS-2DC-6K
- VTOPS
- 500-6000 g
- ≤ ±0.3%
- 2
- 0-30 fills/min
- Vibrator Fillers
- 25 Liters
- 150 Liters
- 850 mm
- AC Single-phase 220V
- 0.5 Kw
- 113×110×227 cm
-
4DC-6K Vtops
- VTOPS-4DC-6K
- VTOPS
- 500-6000 g
- ≤ ±0.3%
- 4
- 0-60 fills/min
- Vibrator Fillers
- 25 Liters
- 180 Liters
- 850 mm
- AC Single-phase 220V
- 0.5Kw
- 150×110×250 cm
3. Video Gallery:
1st. the working video of refined sugar is following:
2st. the working video of grains is following:
3st: 4DC-2K working video:
4st: Irregular Granular llicium verum Packing:
4. Materials Thickness:
| Parts | Materials | Thickness |
|---|---|---|
| Front Window | Plexiglass (Plate) | 6 mm |
| Weighing Bucket (Hopper) | 304 Stainless Steel (Plate) | 1.5 mm |
| Support Frame of Weighing Bucket (Hopper) | 201 Stainless Steel (Plate) | 3.0 mm |
| Discharge Funnel | 304 Stainless Steel (Plate) | 1.5 mm |
| Electrical Control Cabinet | 201 Stainless Steel (Plate) | 1.0 mm |
| Machine Support Frame | 201 Stainless Steel (Square Tube) | 1.7 mm |
| Door Panel | 201 Stainless Steel (Plate) | 1.0 mm |
| Fenders | 201 Stainless Steel (Plate) | 1.0 mm |
| Storage Bucket (Silo) | 304 Stainless Steel (Plate) | 1.5 mm |
| Support Frame of Storage Bucket (Silo) | 201 Stainless Steel (Plate) | 3.0 mm |
