Automatic Piston Filling Machine for High Viscosity Liquid

Automatic piston filling machine is also named high viscosity liquid automatic piston filler. The filling machine is controlled by a servo system, so it has better accuracy and is easier to adjust.
The piston filler machine is widely used in the filling of high viscosity liquid and paste products. Such as: honey, lotion, tomato sauce, rice wine, seafood sauce, grease, lubricants, detergent, washing liquid and other high viscosity liquid.

Servo Pump Liquid Filling Machine

Table of Contents

Zhengzhou Vtops Machinery Co Ltd VTOPS is a reliable labeling machines Supplier from China, and we offer five variants of high-quality can capping machines of mainly two types: snap capper and screw capping machine. Low-cost tin capping sealing machines can free your hands and make capping more efficient.

Features

  • 1. Fill by a special pneumatic three-way valve.
  • 2. The fill volume are adjustment easily.
  • 3. Automatically load and fill containers. Machine will hold stop if no containers.
  • 4. High accuracy fill.
  • 5. PLC controlled. LCD touch screen.
  • 6. The automatic piston filling machine equipped special filling nozzles to prevent dripping.
  • 7. Filling nozzles are the form of down-dive style. Ensure the filling process no bubble and no overflow splash.
  • 8. Sanitary pipeline valves, quick connector, easy removal installation.
  • 9. Plexiglass covered, dust-proof and beautiful.
  • 10. The contact parts are made of food grade 304 stainless steel. Meet GMP standards.

Technical Parameters

  • Model
  • Brand
  • Nozzles
  • Output
  • Filling Capacity
  • Measurement Accuracy
  • Contained Conveyor Belt
  • HMI
  • Control System
  • Filling Control System
  • Voltage
  • Power
  • Air Pressure
  • Dimensions
  • Machine Weight
  • Manufacturer
  • GT-L4 Servo Pump
  • VTOPS-GT-L4
  • VTOPS
  • 4 nozzles (2, 6, 8 are customizable)
  • 5-15 fills/nozzle/min
  • 50 - 500 ml, 100 - 1000 ml, 500 - 3000 ml, 1000 - 5000 ml
  • ≥ ±99%
  • 3 meters
  • LCD Touch Screen
  • PLC
  • Servo System
  • AC Three-phase 380V
  • 1.0 Kw
  • 0.5-0.7 mpa
  • 2000*1200*1800 mm
  • 500 kgs
  • Zhengzhou Vtops Machinery Co., Ltd.

Detailed Photos
