Industrial metal detectors are used in the pharmaceutical, food, beverage, textile, garment, plastics, chemicals, lumber, mining, and packaging industries. Vtops Machinery supply Industrial Metal Detector instruments, as well as sales and services of imported Metal Detector testing equipment, and provide high-level testing solutions. have extensive experience in the removal of metal impurities in the industry and public security inspections, which can meet the high-end needs of professional manufacturers and provide public security inspections. Tailor-made solutions for customers.
Features And Advantages:
The core part is carefully developed with advanced digital technology and original imported chips. The inside of the detection coil is molded at one time by potting, which has the characteristics of high detection accuracy, stable performance, and strong anti-interference ability.
It can be produced in a variety of frequencies according to product characteristics, and has a product testing data storage function, which can store about 100 product testing data, and has a wide range of applications.
Using intelligent recognition technology, with self-learning and memory functions, it can automatically recognize and remember product characteristics, and effectively eliminate the interference caused by various “product effects”.
Simple and friendly operation interface, using a dialogue LCD display, you can quickly and easily set parameters through a simple key control interface; it can detect a variety of products containing different product signals (characteristics), and one setting can ensure extremely high The detection accuracy does not need to be readjusted and set up the program.
Modular component replacement, convenient and quick maintenance.
Comply with HACCP, GMP, FDA requirements.
Shockproof and waterproof design, dustproof and waterproof function in line with IP-66/IP-65 international certification, anti-vibration and noise absorption, can adapt to harsh working environments.
Various reject devices (such as flaps, air blows, push rods, etc.) and lightweight, large-package special and heavy-duty body designs can be adopted according to user needs.
Technical Parameters:
Passing Width(cm)
Passing Height(cm)
FE (Φmm)
NON-FE (Φmm)
SUS304 (Φmm)
Belt width(cm)
Conveyor Length(cm)
Ground Height(cm)
MT-4008
VTOPS
40
08
0.5
0.8
1.0
37
133
75±5
MT-4012
VTOPS
40
12
0.6
1.0
1.2
37
133
75±5
MT-4015
VTOPS
40
15
0.7
1.2
1.5
37
133
75±5
MT-4018
VTOPS
40
18
0.8
1.5
2.0
47
177
75±5
Belt height from the ground(mm): 750±50 Customizable
Protection level: IP66
Quantity of memory products: 100 species
Display mode: LED liquid crystal (Customizable)
Operation mode: Touch key input (touch optional)
Conveyor belt material: Food grade PVC belt (PU belt, sheet chain belt optional)
Alarm mode: Alarm shutdown, buzzer alarm or rejection mechanism optional
Belt speed: 28m/min constant (variable speed for different varieties. Variable frequency speed regulation can be customized if necessary)
Machine material: The whole frame is made of SUS304 food grade stainless steel, which meets HACCP, GMP, FDA, CAS and other standards
Machine weight: About 280KG
Motor: Taiwan high-power motor can transport weight 25-50KG
Power supply: AC Single-phase 220V 50/60Hz
Use environment temperature: Temperature: -18～50℃, relative humidity: 30～90℃
Remarks:
01.Probe detection window, the size of the whole machine can be customized according to customer needs, the higher the detection window height, the lower the detection sensitivity, and the wider the detection window, the detection sensitivity will also decrease.
02.Detection sensitivity is the detection sensitivity obtained by placing the detection card in the center of the conveyor belt through the detection channel.The actual detection sensitivity will vary depending on the product being tested or the conditions of use.
