Description
| Item | VTOPS-S-VN | VTOPS-S-VN Pro | VTOPS-SS-VN |
|---|---|---|---|
| Production Capacity | 6-7 cans/min | 5-6 cans/min | 5-6 cans/min |
| Can Diameter | φ70mm, φ99mm, φ127mm | φ99mm, φ127mm, φ153mm, φ189mm | φ70mm, φ99mm, φ127mm |
| Can Height | 80-190mm | 100-230mm | 80-190mm |
| Degree of Automatic | Fully Inline Automatic | Fully Inline Automatic | Off-line Automatic |
| InlineIntegrated Into Milk Powder Tin Cans Packaging Production Line | |||
| Vacuum Function | |||
| Nitrogen Infill Function | |||
| Negative Pressure Seaming | |||
| Voltage | AC 3-Phase 380V 50Hz | AC 3-Phase 380V 50Hz | AC 3-Phase 380V 50Hz |
| Power | 4 kW | 5.5 kW | 3.3 kW |
| Weight | 500 kg | 650 kg | 350 kg |
| Dimensions | 200×80×185cm | 230×90×195cm | 200×80×185cm |
| Working Pressure (Compressed Air) | ≥0.6MPa | ≥0.6MPa | ≥0.6MPa |
| Air Consumption (Compressed Air) | ≈ 80 L/min | ≈100 L/min | ≈ 80 L/min |
| Nitrogen Source Pressure | ≥0.2MPa | ≥0.2MPa | ≥0.2MPa |
| Nitrogen Consumption | ≈50 L/min | ≈50 L/min | ≈50 L/min |
| Remaining Oxygen | ≤ 3% [1] | ≤ 3% [1] | ≤ 3% [1] | [1]: For special requirements, optional residual oxygen content ≤ 2%. |
